      F24 Code Help – Output to Motor (T-Leads) Disconnected

      F24 (MMX/MMV): Drive Output Leads

      Code Meaning: The drive performs an initial motor continuity check at the beginning of every start. If one or more phase is lost, this code will appear.

      Further Information/Troubleshooting Tips:

      1. Test all connections and wires out to your motor. If you have an overload relay wired between the drive and the motor, check all of the connections on the relay.
      2. Test your motor by measuring resistance leg to leg to validate balance, and check each leg to ground with a meter capable of reading resistance in the mega-ohm range. Make any motor repairs as needed.

      Call PE® for further assistance.
